ADI集成VCO的鎖相環
發布時間：2024-02-29 17:05:56 瀏覽：794
ADI集成VCO的鎖相環適合于通信網絡(COMMS)測試和檢測(ETM)和航天工程/軍事安全(ADEF)應用系統提供本振振蕩器和時鐘源。ADI集成VCO的鎖相環包含窄帶和寬帶器件，同時支持13.6GHz的頻率。ADI集成VCO的鎖相環以及ADI全線產品PLL產品包括整數N分頻PLL和小數N分頻PLL具有優異的噪聲系數性能、震動和雜散性能和高集成度都可以在中小型封裝中實現。
深圳市立維創展科技是ADI的經銷商。ADI芯片產品供應：放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖和光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處置器和DSP、射頻和圖形處置器、開關和分路器等。
大部分產品，均提供現貨庫存供貨。
*部分型號需申請出口許可
歡迎咨詢！！！
產品型號 | Freq Response RF (min) | Freq Response RF (max) | Freq Ref Input (max) | PFD (max) | FOM-Normalized Inband PN Int-N (typ) | FOM-Normalized inband PN Frac-N (typ) | 1/f Noise (10kHz Offset at 1GHz Carrier) (typ) | Pout RF Max (typ) | Is (typ) | Vs+ (min) | Vs+ (max) |
| Hz | Hz | Hz | Hz | dBc/Hz | dBc/Hz | dBc/Hz | dBm | A | V | V |
LTC6948-1 | 370M | 3.74G | 425M | 76.1M | -226 | -225 | -134 | 1.5 | 48m | 3.15 | 3.45 |
LTC6948-2 | 510M | 4.91G | 425M | 76.1M | -226 | -225 | -134 | 1.5 | 48m | 3.15 | 3.45 |
LTC6948-3 | 640M | 5.79G | 425M | 76.1M | -226 | -225 | -134 | 1.5 | 48m | 3.15 | 3.45 |
LTC6948-4 | 700M | 6.39G | 425M | 76.1M | -226 | -225 | -134 | 1.5 | 48m | 3.15 | 3.45 |
AD809 | 155.5M | 155.5M | 19.44M |
|
|
|
|
| 17m | 4.5 | 5.5 |
ADF4350 | 137.5M | 4.4G | 250M | 32M | -220 | -220 | -111 | 5 | 110m | 3 | 3.6 |
ADF4351 | 35M | 4.4G | 250M | 32M | -221 | -221 | -118 | 5 | 110m | 3 | 3.6 |
ADF4355 | 53.125M | 6.8G | 600M | 125M | -223 | -222 | -116 | 8 | 140m | 3.15 | 3.45 |
ADF4355-2 | 53.125M | 4.4G | 600M | 125M | -223 | -222 | -116 | 8 | 140m | 3.15 | 3.45 |
ADF4355-3 | 51.565M | 6.6G | 600M | 125M | -223 | -222 | -116 | 8 | 146m | 3.1515 | 3.4485 |
ADF4356 | 53.125M | 6.8G | 600M | 125M | -227 | -225 | -121 | 4 | 166m | 3.15 | 3.45 |
ADF4360-0 | 2.4G | 2.725G | 250M | 8M | -216 |
|
| -13 | 35m | 3 | 3.6 |
ADF4360-1 | 2.05G | 2.45G | 250M | 8M | -216 |
|
| -13 | 35m | 3 | 3.6 |
ADF4360-2 | 1.85G | 2.17G | 250M | 8M | -216 |
|
| -13.5 | 35m | 3 | 3.6 |
ADF4360-3 | 1.6G | 1.95G | 250M | 8M | -216 |
|
| -12 | 35m | 3 | 3.6 |
ADF4360-4 | 1.45G | 1.75G | 250M | 8M | -216 |
|
| -13 | 35m | 3 | 3.6 |
ADF4360-5 | 1.2G | 1.4G | 250M | 8M | -216 |
|
| -13.5 | 35m | 3 | 3.6 |
ADF4360-6 | 1.05G | 1.25G | 250M | 8M | -216 |
|
| -13.5 | 35m | 3 | 3.6 |
ADF4360-7 | 350M | 1.8G | 250M | 8M | -216 |
|
| -14 | 37.5m | 3 | 3.6 |
ADF4360-8 | 65M | 400M | 250M | 8M | -216 |
|
| -14 | 35m | 3 | 3.6 |
ADF4360-9 | 2M | 200M | 250M | 8M | -218 |
|
| -14 | 23m | 3 | 3.6 |
ADF4368 | 800M | 12.8G | 250M | 625M | -239 | -237 | -147 | 9 |
|
| 5.5 |
ADF4371 | 62.5M | 32G | 600M | 250M | -234 | -233 | -127 | 7 | 260m | 3.15 | 3.45 |
ADF4372 | 62M | 16G | 600M | 250M | -234 | -233 | -127 | 7 | 270M | 3.15 | 3.45 |
ADF4377 | 800M | 12.8G | 1G | 500M | -239 |
| -147 |
|
|
|
|
ADF4378 | 800M | 12.8G | 1G | 500M | -239 |
| -147 |
|
|
|
|
ADF5355 | 54M | 13.6G | 600M | 125M | -223 | -221 | -116 | 8 | 140m | 3.15 | 3.45 |
ADF5356 | 53.125M | 13.6G | 600M | 125M | -227 | -225 | -121 | 4 | 126m | 3.15 | 5.25 |
HMC535 | 14.7G | 15.4G | 240.6M | 240.6M | -110 |
|
| 9 | 340m |
|
|
MAX2870 | 23.5M | 6G | 200M | 105M |
|
|
| 5 | 144m | 3 | 3.6 |
MAX2871 | 23.5M | 6G | 210M | 140M |
|
|
| 5 | 165m | 3 | 3.6 |
MAX2880 | 250M | 12.4G | 210M | 140M |
|
|
|
| 49m | 3 | 3.6 |
MAX9491 | 4M | 200M |
|
|
|
|
|
| 10m | 3 | 3.6 |
