?ADI數字控制可變增益放大器
發布時間：2023-11-20 17:00:42 瀏覽：767
ADI的數字控制可變增益放大器可針對各類音頻和光頻頻段在規則規劃的操控位上供給離散級增益操控。ADI的數字控制可變增益放大器依據用戶能夠實時調整信號起伏，優化了電路元件動態范圍，但這關于涉及到超聲波、語音分析、雷達勘探、無線通訊和儀表設備的各種應用來說是非常重要的。ADI還供給了電壓調節可變增益放大器產品類型，供給寬動態范圍上的連續性增益操控。
產品型號 | Freq Response (min) | Freq Response (max) | Gain dB (min) | Gain dB (max) | Control Step Size | OIP3 (typ) | Is (typ) | Vs span (min) | Vs span (max) |
| Hz | Hz | dB | dB | dB | dBm | A | V | V |
ADL6337A | 500M | 1G | 5.9 | 37.4 | 0.5 | 42 | 460m | 4.75 | 5.25 |
ADL6337B | 1.35G | 2.8G | 4 | 35.5 | 0.5 | 42.5 | 460m | 4.75 | 5.25 |
ADL5206 | 0 | 1.7G | 0 | 32 | 1 | 39.6 | 112m | 3.15 | 5.25 |
ADL6316 | 500M | 1G | -3.4 | 31.1 | 0.45 | 41.8 | 435m | 4.75 | 5.25 |
ADL6317 | 1.5G | 3G | -2.4 | 33.6 | 0.5 | 38.4 | 435m | 4.75 | 5.25 |
ADL5335 | 700M | 4.2G | -8 | 12 | 0.5 | 33 | 125m | 4.75 | 5.25 |
HMC625B | 0 | 5G | -13.5 | 18 | 0.5 | 32 | 87.5m | 4.75 | 5.25 |
ADL5205 | 0 | 1.7G | -9 | 26 | 1 | 46 | 175m | 3.15 | 5.25 |
ADA8282 | 5M | 42.3M | 18 | 36 | 6 |
| 19.6m | 3 | 3.6 |
HMC8120 | 71G | 76G | 7 | 22 | 15 | 30 | 250m | -5 | 4 |
HMC8121 | 81G | 86G | 5 | 22 | 17 | 27.5 | 265m | -5 | 4 |
ADA4961 | 10M | 3.2G | -6 | 15 | 1 | 50 | 150m | 3.3 | 5.5 |
HMC627A | 50M | 1G | -11.5 | 20 |
| 36 | 90m | 5 | 5.5 |
HMC681A | 50M | 1G | 13.5 | 45 | 0.5 | 36 | 176m | 5 | 5.5 |
HMC742A | 70M | 4G | -19.5 | 12 | 0.5 | 39 | 150m | 5 | 5.5 |
MAX19791 | 50M | 4G |
| -3.9 |
|
| 13m | 3.15 | 5.25 |
MAX19793 | 1.5G | 6G |
| -7.6 |
|
| 13m | 3.15 | 5.25 |
MAX19794 | 10M | 500M |
| -3 |
|
| 13m | 3.15 | 5.25 |
ADL5240 | 100M | 4G | -12.6 | 18.2 | 0.5 | 38 | 93m | 4.75 | 5.25 |
ADL5243 | 100M | 4G | -1.2 | 31.3 | 0.5 | 40 | 175.5m | 4.75 | 5.25 |
HMC960 | 0 | 100M | 0 | 40 | 0.5 | 30 | 70m | 4.5 | 5.5 |
MAX2064 | 50M | 1G |
| 22 |
| 41 | 143m | 4.75 | 5.25 |
HMC680 | 30M | 400M | -4 | 19 | 1 | 40 | 250m | 4.5 | 5.6 |
AD8432 | 100k | 200M | 12 | 24 |
| 36.2 | 24m | 4.5 | 5.5 |
LT5554 | 0 | 1G | 2 | 18 | 0.125 | 48 | 110m | 4.75 | 5.25 |
AD8260 | 0 | 195M | -6 | 24 |
|
| 28m | 3.3 | 10 |
MAX2066 | 50M | 1G |
| 20.5 | 1 | 42.4 | 121m | 3.135 | 5.25 |
MAX2065 | 50M | 1G |
| 19.4 | 1 | 42 | 124m | 3.135 | 5.25 |
AD8372 | 10M | 130M | -9 | 32 | 1 | 35 | 212m | 4.5 | 5.5 |
AD8375 | 10M | 630M | -4 | 20 | 1 | 50 | 125m | 4.5 | 5.5 |
AD8376 | 10M | 700M | -4 | 20 | 1 | 50 | 250m | 4.5 | 5.5 |
MAX2058 | 700M | 1.2G |
| 10.5 | 1 | 32.3 | 158m | 4.75 | 5.25 |
LT5524 |
| 540M | 4.5 | 27 | 1.5 | 34 | 34m | 4.75 | 5.25 |
LT5514 |
| 850M | 10.5 | 33 | 1.5 | 41 | 64m | 4.75 | 5.25 |
AD8370 | 10M | 750M | -11 | 34 |
| 35 | 79m | 3 | 5.5 |
MAX2055 | 30M | 300M |
| 20 | 1 | 40 | 240m | 4.75 | 5.25 |
AD8369 | 10M | 600M | -10 | 40 | 3 | 19.5 | 37m | 3 | 5.5 |
MAX2027 | 50M | 400M |
| 15.5 | 1 | 34.7 | 60m | 4.75 | 5.25 |
