?ADI時鐘產生器件
發布時間：2023-06-07 16:56:44 瀏覽：1710
ADI提供極低震動時鐘產生器件，適用于無線網絡基礎設施建設、儀表設備、寬帶網絡、自動測試設備和具體要求亞皮秒特性的技術應用。ADI時鐘產生器件特別適合為性能卓越模數轉換器(ADC)和數模轉換器(DAC)提供高速度、低噪音時鐘信號。ADI的時鐘IC在中小型芯片級封裝中集成化PLL核心、分頻器、相位調制、偏移調整和時鐘驅動器。
深圳市立維創展科技是ADI的分銷商，主要供應放大器、線性產品、數據轉換器、音視頻產品、寬帶產品、時鐘和定時IC、光纖通信產品、接口和間隔、MEMS和傳感器、電源和熱經管、處理器和DSP、射頻和圖形處理器、開關和分配器等。大部分產品，均提供現貨庫存供貨。
詳情了解ADI芯片請點擊：http://m.lunliu2.cn/brand/25.html
產品型號 | Output Frequency (max) | Power (typ) | Ref Clock (min) | Ref Clock (max) |
| Hz | W | Hz | Hz |
ADF4377 | 12.8G |
| 10M | 1G |
AD9546 | 500M | 630m | 1 | 750M |
LTC6952 | 4.5G | 2.6 | 1M | 500M |
AD9542 | 500M | 560m | 2k | 750M |
AD9543 | 500M | 560m | 2k | 750M |
AD9544 | 500M | 560m | 1 | 750M |
AD9545 | 500M | 560m | 1 | 750M |
AD9576 | 1.25G | 619m | 8k | 325M |
AD9530 | 2.7G | 2.3 | 6M | 800M |
LTC6951 | 2.5G | 1.1 | 1M | 425M |
LTC6951-1 | 2.7G | 1.1 | 1M | 425M |
AD9531 | 400M | 600m | 9.5M | 260M |
HMC7044 | 3.2G | 3.4 | 150 | 3.2G |
AD9528 | 1.25G | 1.675 |
| 400M |
AD9574 | 312.5M | 569m | 19.44M | 25M |
AD9578 | 919M | 618m | 20M | 60M |
MAX31180 | 134M |
|
|
|
AD9525 | 3.6G | 1.2 | 0M | 500M |
AD9577 | 637.5M | 1 | 19.44M | 54M |
AD9523-1 | 1G | 898m |
| 400M |
AD9550 | 810M | 450m | 8k | 200M |
AD9523 | 1G | 876m | 42M | 400M |
AD9524 | 1G | 559m | 42M | 400M |
AD9553 | 810M | 450m | 8k | 710M |
AD9575 | 312.5M | 350m | 19.44M | 25.7812M |
AD9571 | 156.25M | 690m | 25M | 25M |
AD9552 | 900M | 400m | 6.6M | 112.5M |
AD9572 | 156.25M | 1 | 25M | 25M |
AD9573 | 100M | 235m | 10M | 25M |
AD9551 | 900M | 560m | 10M | 806M |
AD9516-5 | 2.4G | 1.5 | 0M | 250M |
AD9522-1 | 800M | 1.1 | 0M | 250M |
AD9522-2 | 800M | 1.1 | 0M | 250M |
AD9522-5 | 800M | 1.1 | 0M | 250M |
AD9520-0 | 2.4G | 1.5 | 0M | 250M |
AD9520-1 | 2.4G | 1.5 | 0M | 250M |
AD9520-2 | 2.4G | 1.5 | 0M | 250M |
AD9520-3 | 2.4G | 1.5 | 0M | 250M |
AD9520-4 | 2.4G | 1.5 | 0M | 250M |
AD9520-5 | 2.4G | 1.4 | 0M | 250M |
AD9522-0 | 800M | 1.1 | 0M | 250M |
AD9522-3 | 800M | 1.1 | 0M | 250M |
AD9522-4 | 800M | 1.1 | 0M | 250M |
AD9518-0 | 2.95G | 1.1 | 0M | 250M |
AD9518-1 | 2.95G | 1.1 | 0M | 250M |
AD9518-2 | 2.95G | 1.1 | 0M | 250M |
AD9518-3 | 2.95G | 1.1 | 0M | 250M |
AD9518-4 | 2.95G | 1.1 | 0M | 250M |
AD9516-2 | 2.95G | 1.6 | 0M | 250M |
AD9516-3 | 2.95G | 1.6 | 0M | 250M |
AD9517-0 | 2.95G | 1.4 | 0M | 250M |
AD9517-1 | 2.95G | 1.4 | 0M | 250M |
AD9517-2 | 2.95G | 1.4 | 0M | 250M |
AD9517-3 | 2.95G | 1.4 | 0M | 250M |
AD9517-4 | 2.95G | 1.4 | 0M | 250M |
AD9516-0 | 2.95G | 1.6 | 0M | 250M |
AD9516-1 | 2.95G | 1.6 | 0M | 250M |
AD9516-4 | 2.95G | 1.6 | 0M | 250M |
DS1080L | 134M |
|
|
|
AD9510 | 1.2G | 550m | 0M | 250M |
AD9511 | 1.2G | 550m | 0M | 250M |
AD9512 | 1.2G | 800m | 0M | 1.6G |
AD9540 | 655M | 400m | 10M | 655M |
